Auto Flute Laminating Machine With Self-Developed Feida Paper Feeding Device With Pre-Code Paper Device
Performance characteristics:
The machine adopts a unique pressure spring front gauge design to effectively reduce the mechanical failure rate; Cooperate with intelligent control to ensure accurate fitting and positioning
This machine adopts frequency conversion speed regulation, PLC centralized control, horizontal number conversion and accurate operation control.
The base paper adopts double servo control to realize the timeliness and accuracy from the base paper to the front gauge, and ensure the accuracy of the machine under the running condition.
Glue rolling adopts medium-high design, which is matched with knurling and even glue rolling, thus greatly improving the uniformity of glue rolling, improving the covering strength and reducing the production cost of customers.
The steel rolling has been balanced and tested, and the mechanical stability has been effectively improved with the tight assembly process. In addition, the main transmission adopts timing belt transmission, and the bottom directly adsorbs and feeds paper, which effectively improves the operation accuracy and speed of the machinery.
Using the covering control system, the glue is automatically circulated, which greatly reduces the labor intensity.
Self-developed powerful Feida paper feeding device with pre-code paper device can reduce downtime and improve work efficiency.
All materials used in this machine are inspected according to ISO9001 standard, which is of high quality and strong durability. Imported parts are used for key parts such as bearings.
This machine is suitable for bonding 150-450GSM face paper with A, B, C, D, E, F and three-layer and five-layer paperboard (maximum thickness ≤8 mm).
Main technical parameters
| 机型 | AO-1300M | AO-1450M | AO-1600M | | max size of cover face (W×L) | 1300×1300mm | 1450×1300mm | 1600×1300mm | | mix size of cover face (W×L) | 400×400mm | 400×400mm | 400×400mm | | | | | | | design speed | 6000Sheets/h | 6000Sheets/h | 6000Sheets/h | | gross power | 13kw | 13kw | 13kw | | dimension (long×width×height) | 12000×2250×2655mm | 12000×2400×2655mm | 12000×2550×2655mm | |
| |
